277
Corrective Maintenance
Ribbon T
ake-up Spindle
8/9/07
ZM400/ZM600 Maintenance Manual
14207L-001 A
5.
See
Figure
140
. Remove the four mo
unting scre
ws on the rear of the printer
.
Figure 140 • Remove the Electronics Cover Mount
ing Screws
6.
See
Figu
re
141
. Re
move the electronics cove
r by pressi
ng
in on the ele
ctronics cove
r with
the palm of your hand, and then lif
ting up on the cover
.
Figure 141 • Remove the Electronics Cover
1
Electronics cover
2
Mounting screws
(4)
2
1
2
1
276
278
