Zebra ZM400 Series

399
Corrective Maintenance
Main Logic Board
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
5. See Figure 256. Remove the two wireless mounting standoffs from the MLB.
Figure 256 • Remove the Wireless Board Mounting Standoffs
1
MLB
2
Mounting standoffs (2)
1
2
