Zebra ZM400 Series User Manual

403
Corrective Maintenance
Main Logic Board
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
7. Which communication board do you have?
If you have… Then…
Wired Ethernet a. See Figure 258 on page 400 and reinstall the three mounting
standoffs onto the MLB.
b. See Figure 257 on page 400. Slide the connector on the wired
ethernet board into the mounting hole in the rear panel and then
align the mounting holes with the three studs of the standoffs.
c. Slide the board onto the three studs and then reinstall the three
mounting nuts.
Wireless Ethernet
a. See Figure 256 on page 399 and reinstall the two standoffs onto
the MLB.
b. See Figure 255 on page 398. Slide the wireless board into the
rear panel and then align the two connectors on the MLB with
the two connectors on the wireless board.
c. Press the wireless board into the MLB.
d. Reinstall the three mounting screws.
e. See Figure 254 on page 397. Reinstall the radio board.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
