Zebra ZM400 Series

407
Corrective Maintenance
Wireless Option
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
3. See Figure 264. Remove the four mounting screws on the rear of the printer.
Figure 264 • Remove the Electronics Cover Mounting Screws
4. See Figure 265. Remove the electronics cover by pressing in on the electronics cover with
the palm of your hand, and then lifting up on the cover.
Figure 265 • Remove the Electronics Cover
1
Electronics cover
2
Mounting screws (4)
2
1
2
1
