Corrective Maintenance
Wired Ethernet
416
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
3. See Figure 273. Remove the four mounting screws on the rear of the printer.
Figure 273 • Remove the Electronics Cover Mounting Screws
4. See Figure 274. Remove the electronics cover by pressing in on the electronics cover with
the palm of your hand, and then lifting up on the cover.
Figure 274 • Remove the Electronics Cover
1
Electronics cover
2
Mounting screws (4)
2
1
