Zebra ZM400 Series

Corrective Maintenance
Lower Front Panel
434
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
3. See Figure 290. Tip the new lower front panel up and snap the upper tabs onto the two
mounting hooks.
Figure 290 • Snap to the Mounting Hooks
4. Reconnect the AC power cord and data cables.
5. Turn on (l) the printer.
1
Lower front panel
2
Mounting hooks
1
2
