Drawings and Parts
Repacking Instructions
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
5. Place the bottom left (BL) and bottom right (BR) inserts into the carton, as shown.
6. Place the printer into the carton, aligning the printer front with the front of the inserts. The
front of each insert is marked with a stamped “F.”
7. Place the top left (TL) and top right (TR) inserts into the carton on top of the printer as
shown.
8. Close the flaps, and seal the box with postal quality shipping tape.
9. Label and send insured to:
Zebra Technologies
333 Corporate Woods Parkway
Vernon Hills, Illinois
60060-3109
RMA #XXXXXX
Note • BR=Bottom Right, BL=Bottom Left, TR=Top Right, TL=Top Left.
Note • Write the RMA number on the mailing label and in large letters and numbers on top
of the box.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
