Zebra ZM400 Series User Manual

59
Operations
Load Media
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
2. Slide out the media guide.
3. Insert media into the printer. Follow the instructions for roll or fanfold media, as
appropriate.
Roll Media
Fanfold Media
a. Remove and discard any tags or
labels that are dirty or that are held
by adhesives or tape.
a. Flip down the media supply guide.
b. Flip down the media supply guide. b. Feed the media through the rear or
bottom access slot.
Rear Feed
Bottom Feed
c. Place the roll of media on the media
supply hanger. Push the roll as far
back as it will go.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
