39
Compatible SCPI Commands
SCPI Summary Table
CALCulate<1|2>:DELTamarker<1...4>:MINimu
m:RIGHt
FSE/FSP/FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:LINK
ON | OFF
FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:FIXed[:STATe] ON | OFF
FSE/FSP/FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:FIXed:RPOint:MAXimum[:PEAK]
<numeric_value>
FSP/FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:FIXed:RPOint:Y <numeric_value>
FSE/FSP/FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:FIXed:RPOint:Y:OFFSet <numeric_value>
FSE/FSP/FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:FIXed:RPOint:X <numeric_value>
FSE/FSP/FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:PNOise[:STATe]
FSE/FSP/FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:PNOise:AUTO ON | OFF
FSU Yes
CALCulate<1|2>:DELTamarker<1...4>:FUNCtio
n:PNOise:RESult?
FSE/FSP/FSU Yes
CALCulate<1|2>:LIMit<1...8>:ACTive? FSE/FSU
Yes
a
All LIMit functions are not
supported in CCDF and
APD measurements.
CALCulate<1|2>:LIMit<1...8>:TRACe 1 to 3 FSE/FSP/FSU Yes
CALCulate<1|2>:LIMit<1...8>:STATe ON | OFF FSE/FSP/FSU Yes
CALCulate<1|2>:LIMit<1...8>:UNIT DBM |
DBPW | WATT | DBUV | DBMV | VOLT |DBUA
| AMPere| DB | DEG | RAD | S | HZ | PCT |
UNITLESS
FSE/FSP/FSU Yes The units supported are
DBM, DBPW, WATT,
DBUV, DBMV, VOLT,
DBUA, and DB.
All limit lines use the same
unit.
CALCulate<1|2>:LIMit<1...8>:FAIL? FSE/FSP/FSU Yes
CALCulate<1|2>:LIMit<1...8>:CLEar[:IMMedia
te]
FSE/FSP/FSU Yes
CALCulate<1|2>:LIMit<1...8>:COMMent
<string>
FSE/FSP/FSU Yes
Table 3-1 SCPI Commands Summary Table
SCPI Command Corresponding
Model
Support Notes
