Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
2.40 LVCHIP4 [20H 47H]: V-Chip data acquisition
Function: This command gets the V-Chip data of the designated program number.
When the program number is 0, it reads out the data from the buffer RAM.
When the program has any number from 1001 to 2000, the command reads
out the data from the fixed data. When the program number is 9999, the
command reads the data from the command work RAM.
Sequence: Type 3
Command:
Fig. 2-40-1
Data:
Fig. 2-40-2
Data contents are as below.
Example 1) When all off : “0”
Example 2) When only FV is On : “16”
Example 3) when V and L are On : “10”
Example 4) When V, S, L are On : “14”
