2.130 S3DIMG4［20H B5H］ :3D Image pattern data setting
Function : This command gets 3D Image pattern data of the indicated program No. In case
program NO.1001 to 2000, the VG original data is read out. In case ,NO.9999, the
data is read out from command work RAM.
Sequence : TYPE 3
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
S3DPAT4
2 BYTE
20H B5H
Program NO
1-4 BYTE
"0"-"1000","9999"
Chapter 16 ,
1 BYTE
2CH (Delimiter)
ImageType
1 BYTE
"0"=Bitmap
"1"=MonoScope
"2"=China Pattern
,
1 BYTE
2CH (Delimiter)
LeftImage
1-3 BYTE
"1"-"200"
,
1 BYTE
2CH (Delimiter)
RightImage
1-3 BYTE
"1"-"200"
,
1 BYTE
2CH (Delimiter)
LeftDeviation
2-5 BYTE
"12048"-"02048" (-2048 to 2048)
,
1 BYTE
2CH (Delimiter)
RightDeviation
2-5 BYTE
"12048"-"02048" (-2048 to 2048)
,
1 BYTE
2CH (Delimiter)
LR ON/OFF
1-2 BYTE
"0"=L / R ON
"1"=L ON / R OFF
"2"=L OFF / R ON
"3"=L ON / R(O) ON / R(E) OFF
"4"=L ON / R(O) OFF / R(E) ON
"5"=L OFF / R(O) ON / R(E) OFF
"6"=L OFF / R(O) OFF / R(E) ON
"7"=L(O) ON / L(E) OFF / R ON
"8"=L(O) OFF / L(E) ON / R ON
"9"=L(O) ON / L(E) OFF / R OFF
"10"L(O) OFF / L(E) ON / R OFF
"11"=L(O) ON / L(E) OFF / R(O) ON / R(E) OFF
"12"=L(O) ON / L(E) OFF / R(O) OFF / R(E) ON
"13"=L(O) OFF / L(E) ON / R(O) ON / R(E) OFF
"14"=L(O) OFF / L(E) ON / R(O) OFF / R(E) ON
,
1 BYTE
2CH (Delimiter)
Color R
(When L/R is OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Color G
(When L/R is OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Color B
(When L/R is OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Level L
(When L/R is ON)
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
Level R
(When L/R is ON)
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
