ASTRO VG-871 - SLGRP5 [20 H 9 FH]: Large Group Data Registration

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
203
2.110 SLGRP5 [20H 9FH] : Large group data registration
Function : This command registers indicated large group No. data.
Sequence : TYPE2
Command:
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
SLGRP5
2 BYTE
20H 9FH
Large group NO
1-2 BYTE
"1"～"99"
,
1 BYTE
2CH (Delimiter)
Character number of
large group name.
1-2 BYTE
"1"-"20"
,
1 BYTE
2CH (Delimiter)
Large group name
20 BYTE
20 ASCII characters (When the string contains
fewer than 20 characters, enter spaces after the
characters to bring the number of characters up to
20)
,
1 BYTE
2CH (Delimiter)
#1
Slot No.
1-2 BYTE
"0"-"11"
,
1 BYTE
2CH (Delimiter)
Board Type
1 BYTE
"1"-"5"
"1"=HDMI
"2"=HDMI & VGA
"3"=TVAnalog(YPbPr)
"4"=TVAnalog(D5)
"5"=Scart
Note) 0 is invalid.
,
1 BYTE
2CH (Delimiter)
#1-1
Execution sequence No.
1-2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Small group No.
1-2 BYTE
"0"-"99" ("0"=unregistered)
,
1 BYTE
2CH (Delimiter)
#1-2
Execution sequence No.
1-2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Small group No.
1-2 BYTE
"0"-"99" ("0"=unregistered)
,
1 BYTE
2CH (Delimiter)
#1-3
Execution sequence No.
1-2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Small group No.
1-2 BYTE
"0"-"99" ("0"=unregistered)
,
1 BYTE
2CH (Delimiter)
#4
Slot No.
1-2 BYTE
"0"-"11"
,
1 BYTE
2CH (Delimiter)
Board Type
1 BYTE
"1"-"5"
"1"=HDMI
"2"=HDMI & VGA
"3"=TVAnalog(YPbPr)
"4"=TVAnalog(D5)
"5"=Scart
Note) 0 is invalid.
,
1 BYTE
2CH (Delimiter)
#4-1
Execution sequence No.
1-2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Small group No.
1-2 BYTE
"0"-"99" ("0"=unregistered)
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
