Chapter 4 INDIVIDUAL FORMATS FOR CONTROL COMMANDS
337
3.38 VG drawing command table
Code 1
Code 2
Command
Description
Type
28H
20H
CHACLR4
Character plane clear
2
28H
21H
CHAPSET4
Character plane dot drawing
2
28H
22H
CHALINE4
Character plane straight line drawing
2
28H
23H
CHASQRE4
Character plane square drawing
2
28H
24H
CHASQPA4
Character plane filled-in square drawing
2
28H
25H
CHACIRC4
Character plane circle drawing
2
28H
26H
CHACIRCPA4
Character plane filled-in circle drawing
2
28H
27H
CHAELPS4
Character plane ellipse drawing
2
28H
28H
CHAELPSPA4
Character plane filled-in ellipse drawing
2
28H
29H
CHATRI4
Character plane triangle drawing
2
28H
2AH
CHATRIPA4
Character plane filled-in triangle drawing
2
28H
2BH
CHABITBLT4
Character plane area copy
2
28H
2CH
CHACOL4
Character plane color setting
2
28H
2DH
CHASTR4
Character plane character string draw
2
28H
40H
GRACLR4
Graphic plane clear
2
28H
41H
GRAPSET4
Graphic plane dot drawing
2
28H
42H
GRALINE4
Graphic plane straight line drawing
2
28H
43H
GRASQRE4
Graphic plane square drawing
2
28H
44H
GRASQPA4
Graphic plane filled-in square drawing
2
28H
45H
GRACIRC4
Graphic plane circle drawing
2
28H
46H
GRACIRCPA4
Graphic plane filled-in circle drawing
2
28H
47H
GRAELPS4
Graphic plane ellipse drawing
2
28H
48H
GRAELPSPA4
Graphic plane filled-in ellipse drawing
2
28H
49H
GRATRI4
Graphic plane triangle drawing
2
28H
4AH
GRATRIPA4
Graphic plane filled-in triangle drawing
2
28H
4BH
GRABITBLT4
Graphic plane area copy
2
28H
4CH
GRACOL4
Graphic plane color setting
2
28H
4DH
GRALEV4
Graphic Plane Level Edit
2
28H
4EH
GRAPAL4
Graphic plane palette mode
2
28H
4FH
GRAMPAL4
Graphic plane multiple color setting
2
28H
60H
ALLCLR4
All planes clear
2
28H
61H
WINDOW4
Window drawing
2
28H
62H
WINDCL4
Window color setting
2
28H
63H
WINCLR4
Window plane clear
2
28H
70
ALLSCOL4
RGB output and color setting
2
28H
71
BCOL4
Background color setting
2
28H
72
CAP4
Capture execution
2
