2.118 S3DPAT4［20H A9H］ :OPT 3D pattern data setting
Function : This command sets OPT 3D pattern data of the indicated program No. In case,
program No.0, the data is saved in buffer RAM temporally. In case, NO.9999, the
data is saved in command work RAM.
Sequence : TYPE2
Command ：
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
S3DPAT4
2 BYTE
20H A9H
Program NO
1-4 BYTE
"0"-"1000","9999"
,
1 BYTE
2CH (Delimiter)
Type
1-2 BYTE
"0"= Color bar V-1
"1"= Color bar V-2
"2"= Vertical bar
"3"= Checker dot
"4"= Checker block
"5"= Slant color bar
"6"= Raster
"7"= □×＋○
"8"= Window
"9"= Circle
"10"= 9 Window
"11"= 9 Circle
"12"= Slant gray bar
"13"= Cross Hatch
,
1 BYTE
2CH (Delimiter)
LR ON/OFF
1-2 BYTE
"0"=L / R ON
"1"=L ON / R OFF
"2"=L OFF / R ON
"3"=L ON / R(O) ON / R(E) OFF
"4"=L ON / R(O) OFF / R(E) ON
"5"=L OFF / R(O) ON / R(E) OFF
"6"=L OFF / R(O) OFF / R(E) ON
"7"=L(O) ON / L(E) OFF / R ON
"8"=L(O) OFF / L(E) ON / R ON
"9"=L(O) ON / L(E) OFF / R OFF
"10"L(O) OFF / L(E) ON / R OFF
"11"=L(O) ON / L(E) OFF / R(O) ON / R(E) OFF
"12"=L(O) ON / L(E) OFF / R(O) OFF / R(E) ON
"13"=L(O) OFF / L(E) ON / R(O) ON / R(E) OFF
"14"=L(O) OFF / L(E) ON / R(O) OFF / R(E) ON
,
1 BYTE
2CH (Delimiter)
Color R
(When L or R is set OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Color G
(When L or R is set OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Color B
(When L or R is set OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Level L
(When L or R is set ON)
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
