2.18 LWFL4 [20H 31H]: Window level flicker data
readout
Function: This command reads the window level flicker data of the designated
program. When the program number is 0, it reads out the data from the
buffer RAM. When the program has any number from 1001 to 2000, the
command reads out from the fixed data. When the program number is 9999,
the command reads the data from the command work RAM.
Sequence: Type 3
Command:
Fig. 2-18-1
Data:
“0” = Not provided, “1” = Provided
“1” to “9999” (“0” = Not registered)
“1” to “255” (“0” = Not registered)
Fig. 2-18-2
