ASTRO VG-871 - EXEPIF4[24 H 43 H]: Set Slot No. and Terminal No. to be Executed or Transmitted

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
281
2.167 EXEPIF4[24H 43H] : set slot No. and terminal No. to be
executed or transmitted.
Function : this command sets slot No. and terminal No. to be executed or transmitted.
Sequence : Type 2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
EXEPIF4
2 BYTE
24H 43H
Slot No
1 BYTE
"0"-"4" Note : "0" means ALL
,
1 BYTE
2CH (Delimiter)
Terminal No.
1 BYTE
"1"-"3"
ETX
1 BYTE
03H
Fig 2.167-1
Note1 : this command is only for VG-881.
Note2 : before executing program by command in VG-881, use this
command first. However, in case of receiving command, “All” setting of
Slot No. will show error.
PC
VG
STX～ETX
ACK or
STX+ESTS+Error Code+ETX
