ASTRO VG-871 - S9 Marker4 [20 H 8 BH]: OPT 9 Marker Data Setting

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
185
2.98 S9Marker4 [20H 8BH] : OPT 9 Marker data setting.
Function ： This command set the Option 9 Marker data of the indicated program No. The data is
saved in Buffer RAM temporally in case of program No.0. The data is saved in this RAM will be
disappeared when VG power is turned off. In case of No.9999, this data is saved in command
work RAM which saves the command code temporary.
Sequence ： TYPE2
Command ：
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
S9Marker4
2 BYTE
20H 89H
PROGRAM NO
1 to 4 BYTE
"0" to "1000","9999"
,
1 BYTE
2CH（Delimiter）
Type
1 BYTE
"0"=Circle、"1"=Rectangle, “2”=Line
,
1 BYTE
2CH（Delimiter）
Mark Num
1 BYTE
"0" to "9"
,
1 BYTE
2CH（Delimiter）
#1
Pos X
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
Pos Y
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
#9
Pos X
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
Pos Y
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
Size
1 to 4 BYTE
"1" to "9999"
*In case Type is circle, the value should be the
radius. In case, rectangle, the value is the
distance from center.
,
1 BYTE
2CH（Delimiter）
Filling marker
1 BYTE
"0"=OFF、"1"=ON
,
1 BYTE
2CH（Delimiter）
Line width
1 to 2 BYTE
"1" to "15"
* It is ON in case not filling line.
,
1 BYTE
2CH（Delimiter）
Color R
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color G
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color B
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Edit Bit Mode
1 to 2 BYTE
"8" to "16"
,
1 BYTE
2CH（Delimiter）
Vertical line / Horizontal line
mode.
1 BYTE
"0"=OFF
"1"=Vertical line
"2"=Horizontal line
"3"=Vertical/Horizontal line
,
1 BYTE
2CH（Delimiter）
The width of vertical line /
horizontal line.
1 to 2 BYTE
"1" to "15"
,
1 BYTE
2CH（Delimiter）
Center coordinates X of vertical
1 to 4 BYTE
"0" to "4095"
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
