2.104 SVBO4 [20H 97H] : VbyOne data setting
Function : This command gets VbyOne data of the indicated program No. In case, program No.0,
the data is saved in buffer RAM temporally. In case, NO.9999, the data is saved in
command work RAM.
Sequence : TYPE2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
SVBO4
2 BYTE
20H 97H
Program NO
1 - 4 BYTE
"0" - "1000","9999"
,
1 BYTE
2CH（Delimiter）
Lane number
1 BYTE
"0"=AUTO
"1"=1 Lane
"2"=2 Lane
"3"=4 Lane
"4"=8 Lane
"5"=16 Lane
,
1 BYTE
2CH（Delimiter）
PreEmphasis
1 BYTE
"0"=0% "1"=100%
,
1 BYTE
2CH（Delimiter）
VbyOne Field Bet Mode
1 BYTE
"0"=Disable "1"=Enable
,
1 BYTE
2CH（Delimiter）
Lane Distribute Mode
1 BYTE
"0"=Normal "1"=Distribution
,
1 BYTE
2CH（Delimiter）
240Hz Enable
1 BYTE
"0"=Disable "1"=Enable
,
1 BYTE
2CH（Delimiter）
Split Mode*
1 BYTE
8 lane
16 lane
“0”
Cross split to
4 part
Cross split to 4 part +
Vertically 2-split
“1”
Vertically 4-split
Vertically 4-split +
Vertically 2-split
“2”
Horizontally
4-split
Horizontally 2-split +
Vertically 2-split
“3”
Vertically 2-split
Vertically 2-split +
Vertically 2-split
“4”
No split
“5”
Vertically 8-split
Vertically 2-split +
Vertically 8-split
* This command is active when lane number
is 8 or 16.
,
1 BYTE
2CH（Delimiter）
240Hz BitMode*
1 BYTE
8 lane
16 lane
“0”
Non dividing mode
“1”
Normal mode
“2”
Cross mode
“3”
Dividing Normal Mode
“4”
Dividing Cross Mode
“5”
No split
* This command is active when “ 240Hz
enalble” is “ Enable”.
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
