6.2.2 Settings established using H timing setting command
H timing data registration: Command [20H 20H]
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
SHT4
0×20
0×20
Program number
0×31
“1”
Delimiter
0×2C
“, “
μ/dot = dot
0×31
“1”
Delimiter
0×2C
“, “
Repetition
0×31
“1”
Delimiter
0×2C
“, “
DotClock = 65000000 Hz
0×36
“6”
0×35
“5”
0×30
“0”
0×30
“0”
0×30
“0”
0×30
“0”
0×30
“0”
0×30
“0”
Delimiter
0×2C
“, “
H-PERIOD = 1352
0×31
“1”
0×33
“3”
0×35
“5”
0×32
“2”
Delimiter
0×2C
“, “
H-DISPLAY = 1024
0×31
“1”
0×30
“0”
0×32
“2”
0×34
“4”
Delimiter
0×2C
“, “
H-SYNC = 96
0×39
“9”
0×36
“6”
Delimiter
0×2C
“, “
H-BACK-PORCH = 202
0×32
“2”
0×30
“0”
0×32
“2”
Delimiter
0×2C
“, “
HD-START = 0
0×30
“0”
Delimiter
0×2C
“, “
HD-WIDTH = 0
0×30
“0”
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
