2.128 SSMD3D4［20H B3H］ :SMD 3D Pattern data setting
Function : This command sets SMD 3D pattern data of the indicated program No. In case,
program No.0, the data is saved in buffer RAM temporally. In case, NO.9999, the
data is saved in command work RAM.
Sequence : TYPE2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
SPOWER4
2 BYTE
20H B3H
Program NO
1-4 BYTE
"0"-"1000","9999"
,
1 BYTE
2CH (Delimiter)
Bit Mode
1-2 BYTE
"8"-"16"
,
1 BYTE
2CH (Delimiter)
Pattern Type
1-5 BYTE
"0"= Perfect circle
"1"= Square
,
1 BYTE
2CH (Delimiter)
Pattern Size
1-5 BYTE
"0"-"100"
,
1 BYTE
2CH (Delimiter)
Marker OnOff
1-4 BYTE
"0"= Off
"1"= On
,
1 BYTE
2CH (Delimiter)
OutputMode
1 BYTE
"0"=3D Structure "1"=Frame Sequential
,
1 BYTE
2CH (Delimiter)
Left Position X
1-4 BYTE
"0"-"640"
,
1 BYTE
2CH (Delimiter)
Left Position Y
1-5 BYTE
"0"-"480"
,
1 BYTE
2CH (Delimiter)
Right Position X
1-4 BYTE
"0"-"640"
,
1 BYTE
2CH (Delimiter)
Right Position Y
1-5 BYTE
"0"-"480"
,
1 BYTE
2CH (Delimiter)
LeftColor R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
LeftColor G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
LeftColor B
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
RightColor R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
RightColor G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
RightColor B
1-5 BYTE
"0"-"65535"
ETX
1 BYTE
03H
Fig 2-128-1
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
