ASTRO VG-871 - Chapter 6 EXAMPLES of USAGE

461
6
6
EXAMPLES OF USAGE
6.1 Executing the internal timing data
Example: If internal timing data No.1001 is to be executed, then:
Tim/Pat No.
No.
1001
6.1.1 Flow of commands used
6.1.2 Command settings
Program data execution: Command [24H 20H]
Parameters:
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
EXPDN4
0×24
“$”
0×20
Program number
0×31
“1”
0×30
“0”
0×30
“0”
0×31
“1”
Delimiter
0×2C
“, “
Execution mode (Timing)
0×31
“1”
ETX
0×03
* ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
ENQ [05H]
EXPDN4 [24H 20H]
Program data
execution command
END
Execution
command
