Chapter 6 EXAMPLES OF USAGE
475
6.4.2 Settings established using pattern data output ON/OFF setting
command
Pattern data output ON/OFF setting: Command [20H 30H]
Setting item
Setting value
Binary
ASCII
STX
0×02
VGCMD4
0×FD
EXPONOFF4
0×20
0×30
“0”
Mode
0×30
“0”
Delimiter
0×2C
“, “
Pattern select code = R
0×30
“0”
Delimiter
0×2C
“, “
Pattern select code = G
0×31
“1”
Delimiter
0×2C
“, “
Pattern select code = B
0×32
“2”
Delimiter
0×2C
“, “
Pattern select code = Raster
0×31
“1”
0×30
“0”
Delimiter
0×2C
“, “
Pattern select code = Window
0×31
“1”
0×39
“9”
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
