ASTRO VG-871 - SDIV4 [20 H BDH]: Dotclk Mode Data Setting

242
2.134 SDIV4 [20H BDH] : DotClk Mode Data setting
Function : This command sets Dot Clock Mode data of the indicated program No. In case,
program No.0, the data is saved in buffer RAM temporally. In case, NO.9999, the
data is saved in command work RAM.
Sequence : TYPE2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
SDIV4
2 BYTE
20H BDH
Program NO
1-4 BYTE
"0"-"1000","9999"
,
1 BYTE
2CH (Delimiter)
DotClk Mode
1 BYTE
"0"=Auto
"1"=Single
"2"=Dual
"3"=Quad
,
1 BYTE
2CH (Delimiter)
Split Mode
1-2 BYTE
"0"-"10"
ETX
1 BYTE
03H
Fig. 2.134-1
PC
VG
STX-ETX
ACK or
STX+ESTS+Error Code+ETX
