ASTRO VG-871 - SHAN4 [20 H A5 H]: N Value Data Setting

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
213
2.116 SHAN4 [20H A5H] : N value data setting
Function : This command sets N value of the indicated program No. In case, program No.0,
the data is saved in buffer RAM temporally. In case, NO.9999, the data is saved in
command work RAM.
Sequence ： TYPE2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
SHAN4
2 BYTE
20H A5H
Program NO
1-4 BYTE
"0"-"1000","9999"
Chapter 15 ,
1 BYTE
2CH (Delimiter)
Mode
1 BYTE
"0"=AUTO, "1"=Manual
,
1 BYTE
2CH (Delimiter)
N value
3-4 BYTE
"300""1500"
Note) this is used when “Mode” is set as
Manual
ETX
1 BYTE
03H
Fig 2-116-1
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
