ASTRO VG-871 - Settings Established Using Pattern Data Setting Command

470
6.3.3 Settings established using pattern data setting command
Pattern data registration: Command [20H 2CH]
Parameters:
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
SPT4
0×20
0×2C
“, “
Program number
0×31
“1”
Delimiter
0×2C
“, “
Pattern block No.
0×31
“1”
0×30
“0”
Delimiter
0×2C
“, “
Type = Custom
0×30
“0”
Delimiter
0×2C
“, “
MODE = %
0×30
“0”
Delimiter
0×2C
“, “
Valid number = 16
0×31
“1”
0×36
“6”
Delimiter
0×2C
“, “
H width = 6.3%
0×36
“6”
0×33
“3”
Delimiter
0×2C
“, “
V width = 6.3%
0×36
“6”
0×33
“3”
Delimiter
0×2C
“, “
Direction H/V
= Horizontal direction
0×30
“0”
Delimiter
0×2C
“, “
Color specification 1 = White
0×37
“7”
Color specification 2 = Yellow
0×33
“3”
Color specification 3 = Cyan
0×36
“6”
Color specification 4 = Green
0×32
“2”
Color specification 5 = Magenta
0×35
“5”
Color specification 6 = Red
0×31
“1”
Color specification 7 = Blue
0×34
“4”
Color specification 8 = Black
0×30
“0”
Color specification 9 = White
0×37
“7”
Color specification 10 = Yellow
0×33
“3”
Color specification 11 = Cyan
0×36
“6”
Color specification 12 = Green
0×32
“2”
Color specification 13 = Magenta
0×35
“5”
Color specification 14 = Red
0×31
“1”
Color specification 15 = Blue
0×34
“4”
Color specification 16 = Black
0×30
“0”
Delimiter
0×2C
“, “
Level 0 = 100%
0×31
“1”
0×30
“0”
0×30
“0”
0×30
“0”
Delimiter
0×2C
“, “
Level 1 = 100%
0×31
“1”
0×30
“0”
0×30
“0”
0×30
“0”
Delimiter
0×2C
“, “
~
