2.132 SCON4 [20H BBH] : Output terminal setting
Function : This command sets Output terminal data of the indicated program No. In case,
program No.0, the data is saved in buffer RAM temporally. In case, NO.9999, the
data is saved in command work RAM.
Sequence : TYPE2
Command :
Output terminal information
#1
Output terminal information
#2
Output terminal information
#N
Fig. 0-1
* About output terminal code, refer to Fig.2-132-2 for VG-870, 871 and 880. Refer to Fig. 2-132-3 for VG-882
and VG-883. Refer to Fig. 2-132-4 for VG-884. Refer to Fig.2-132-5 for VG-876.
* If the output terminal code that does not exist in VG, it is ignored.
ACK or
STX+ESTS+Error Code+ETX
