2.53 LINB4 [20H 57H]: Black insertion data readout
Function: This command reads the black insertion data of the designated program
number. When the program number is 0, it reads out the data from the
buffer RAM. When the program has any number from 1001 to 2000, the
command reads out from the fixed data. When the program number is 9999,
the command reads the data from the command work RAM.
Sequence: Type 3
Command:
Fig. 2-53-1
Data:
“0” = Disable, “1” = Enable
“0” = All, “1” = Left, “2” = Right
“0” to “255” (0 to 255 V)
“0” to “255” (0 to 255 V)
Fig. 2-53-2
