ASTRO VG-871 - STELOP4 [20 H 91 H]: Subtitle Data Setting

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
189
2.100 STELOP4 [20H 91H] : Subtitle data setting.
Function : This command sets subtitle data of the indicated program No. In case, program No.0, this
data is saved in Buffer RAM temporally in case, NO.9999, the data is recorded in command
work RAM.
Sequence : TYPE2
Command ：
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
STELOP4
2 BYTE
20H 91H
Program NO
1 to 4 BYTE
"0" to "1000","9999"
,
1 BYTE
2CH（Delimiter）
Telop NO
1 to 3 BYTE
"1" to "200"
,
1 BYTE
2CH（Delimiter）
Position
1 BYTE
"0"=Indication of coordinate, "1"=Upper left
"2"=Middle left, "3"=Bottom left
"4"=Upper middle, "5"=Middle
"6"=Bottom middle, "7"=Upper right
"8"=Middle right, "9"=Bottom right
,
1 BYTE
2CH（Delimiter）
Position X
1 to 4 BYTE
"1" to "9999" *This is ON incase Position is 0.
,
1 BYTE
2CH（Delimiter）
Position Y
1 to 4 BYTE
"1" to "9999" *This is ON incase Position is 0.
,
1 BYTE
2CH（Delimiter）
Color Enable
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH（Delimiter）
Color0 R
1 to 5 BYTE
"0" to "65535" *This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color0 G
1 to 5 BYTE
"0" to "65535" *This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color0 B
1 to 5 BYTE
"0" to "65535" *This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color1 R
1 to 5 BYTE
"0" to "65535"
*This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color1 G
1 to 5 BYTE
"0" to "65535"
*This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color1 B
1 to 5 BYTE
"0" to "65535"
*This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color2 R
1 to 5 BYTE
"0" to "65535"
*This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color2 G
1 to 5 BYTE
"0" to "65535"
*This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Color2 B
1 to 5 BYTE
"0" to "65535"
*This is ON in case, Color Enable is 1.
,
1 BYTE
2CH（Delimiter）
Bit Mode
1 to 2 BYTE
"8" to "16"
ETX
1 BYTE
03H
Fig. 2-100-1
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
