188
horizontal line.
,
1 BYTE
2CH（Delimiter）
Center coordinates X of
vertical line / horizontal line.
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
The center coordinates Y of
Vertical / Horizontal line.
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
The color of Vertical line /
horizontal line R
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
The color of Vertical line /
horizontal line G
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
The color of Vertical line /
horizontal line B
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Type 1 of Line
1 BYTE
"0"=horizontal line,
"1"=vertical line
Note) this is ON when Type is
selected as 2=Line.
#1
,
1 BYTE
2CH（Delimiter）
Type 9 of Line
1 BYTE
"0"=horizontal line,
"1"=vertical line
Note) this is ON when Type is
selected as 2=Line.
#9
ETX
1 BYTE
03H
Fig. 2-99-2
