Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
253
2.144 HDCPON4 [24H 28H]: HDCP execution start/stop
Function: This command starts or stops the HDCP execution.
Sequence: Type 2
Command:
STX
1 byte
02H
VG4CMD
1 byte
FDH
HDCPON4
2 bytes
24H 28H
HDCP execution
1 byte
“0” = Stop, “1” = Start
ETX
1 byte
03H
Fig. 2-144-1
