6.2 Setting and executing the H and V timing data
The command settings used from setting the H and V timing data to executing the data are listed
below.
Example: If the H and V timing data shown below are to be set in program No.0001 and executed,
then:
H Timing
V Timing
μ/dot
1
SCAN MODE
0
Repetition
1
SERRATION
0 H
DotClock
65.00 MHz
ENQ ON/OFF
0 H
H-PERIOD
1352 dots
V-TOTAL
804 H
H-DISPLAY
1024 dots
V-SYNC
4 H
H-SYNC
96 dots
ENQ-FP
0 H
H-BACK-PORCH
202 dots
ENQ-BP
0 H
HD-START
0 dot
V-BACK-PORCH
29 H
HD-WIDTH
0 dot
V-DISPLAY
768 H
VD-START
0 H
VD-WIDTH
0 H
V-TOTAL2
80 H
V-SYNC2
1 H
ENQ-FP2
0 H
ENQ-BP2
0 H
V-BACK-PORCH2
0 H
V-DISPLAY2
2 H
VD-START2
0 H
VD-WIDTH2
0 H
TvMode
Other
Category1 to 32
0
Note) the above data set Scan Mode as “0 (non-interlace)”. Therefore, only the 1
st
field
data is available as field data. However, if you set all 0 in the 2
nd
field, it will show data
area check error. Therefore, the example sets the same data of the 1
st
field in the 2
nd
field.
1
st
field
2
nd
field
