Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
209
2.114 SSDI4 [20H A3H] : SDI data setting
Function : This command gets SDI data of the indicated program No. In case, program No.0,
the data is saved in buffer RAM temporally. In case, NO.9999, the data is saved in
command work RAM.
Sequence : TYPE2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
SSDI4
2 BYTE
20H A3H
Program NO
1-4 BYTE
"0"-"1000","9999"
Chapter 14 ,
1 BYTE
2CH (Delimiter)
SDI Format
1 BYTE
"0"=SD "1"=HD "2"=3G-A "3"=3G-B "4"=DUAL
"5"=3D (VG-876 does not support it.)
,
1 BYTE
2CH (Delimiter)
Video Format
1 BYTE
"0"=RGB "1"=YC:444 "2"=YC:422
,
1 BYTE
2CH (Delimiter)
BitWidth
1 BYTE
"0"=Auto "1"=10bit "2"=12bit
,
1 BYTE
2CH (Delimiter)
Audio Out Enable
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
Payload Data Format
1 BYTE
"0" fixed
,
1 BYTE
2CH (Delimiter)
Payload ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
Transport
1 BYTE
"0"=Interlace "1"=Progressive
,
1 BYTE
2CH (Delimiter)
1 BYTE
"0"=Interlace "1"=Progressive
,
1 BYTE
2CH (Delimiter)
PictureRate
1 BYTE
"0"=23.98Hz "1"=24Hz "2"=25Hz "3"=29.97Hz
"4"=30Hz "5"=50Hz "6"=59.94Hz "7"=60Hz
Below is available only for VG-876.
"8"=47.95Hz, "9"=48Hz
,
1 BYTE
2CH (Delimiter)
AspectRatio
1 BYTE
"0"=4:3 "1"=16:9
,
1 BYTE
2CH (Delimiter)
Sampling Structure
1 BYTE
"0"=4:2:2(YCbCr)
"1"=4:4:4(YCbCr)
"2"=4:4:4(RGB)
"3"=4:4:4:4(YCbCr+A)
"4"=4:4:4:4(RGB+A)
“5”=4:4:4 (XYZ)
Below is available only for VG-876.
"6"=4:2:0
"7"=4:2:2:4(YCbCr+A)
"8"=4:2:2:4(YCbCr+D)
"9"=4:4:4:4(YCbCr+D)
"10"=4:4:4:4(RGB+D)
,
1 BYTE
2CH (Delimiter)
DynamicRange
1 BYTE
"0"=100% "1"=200% "2"=400%
,
1 BYTE
2CH (Delimiter)
BitDepth
1 BYTE
"0"=8bit "1"=10bit "2"=12bit
,
1 BYTE
2CH (Delimiter)
Payload H YSampling
1 BYTE
"0"-"1"
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
