2.99 L9Marker4［20H 8CH］:OPT 9 Marker data acquisition
Function : This command gets the data of Option 9Marker of the indicated program No. In
case NO.1001 to 2000 program, original data of VG is read. In case NO.9999,
the data is read out from command work ROM.
Sequence : TYPE 3.
Parameter ：
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
L9Marker4
2 BYTE
20H 8CH
Program NO
1 to 4 BYTE
"0" to "2000","9999"
ETX
1 BYTE
03H
Fig. 2-99-1
Data ：
STX
1 BYTE
02H
TRDT
1 BYTE
10H
Type
1 BYTE
"0"=Circle、"1"=Rectangle, "2"=Line
,
1 BYTE
2CH（Delimiter）
Mark Num
1 BYTE
"0" to "9"
,
1 BYTE
2CH（Delimiter）
#1
Pos X
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
Pos Y
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
#9
Pos X
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
Pos Y
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
Size
1 to 4 BYTE
"1" to "9999"
*In case Type is circle, the value should
be the radius. In case, rectangle, the
value is the distance from center.
,
1 BYTE
2CH（Delimiter）
Filling marker
1 BYTE
"0"=OFF, "1"=ON
,
1 BYTE
2CH（Delimiter）
Line width
1 to 2 BYTE
"1" to "15"
* It is ON in case not filling line.
,
1 BYTE
2CH（Delimiter）
Color R
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color G
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color B
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Edit Bit Mode
1 to 2 BYTE
"8" to "16"
,
1 BYTE
2CH（Delimiter）
Vertical line / Horizontal line
mode.
1 BYTE
"0"=OFF
"1"=Vertical line
"2"=Horizontal line
"3"=Vertical/Horizontal line
,
1 BYTE
2CH（Delimiter）
The width of vertical line /
1 to 2 BYTE
"1" to "15"
PC
VG
STX～ETX
STX+TRDT+DATA+ETX
ACK or
STX+ESTS+ERROR CODE+ETX
