186
line / horizontal line.
,
1 BYTE
2CH（Delimiter）
The center coordinates Y of
Vertical / Horizontal line.
1 to 4 BYTE
"0" to "4095"
,
1 BYTE
2CH（Delimiter）
The color of Vertical line /
horizontal line R
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
The color of Vertical line /
horizontal line G
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
The color of Vertical line /
horizontal line B
1 to 5 BYTE
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Type 1 of Line
1 BYTE
"0"=horizontal line, "1"=vertical line
Note) this is ON when Type is
selected as 2=Line.
＃1
1 BYTE
2CH（Delimiter）
Type 9 of Line
"0"=horizontal line, "1"=vertical line
Note) this is ON when Type is
selected as 2=Line.
＃9
ETX
1 BYTE
03H
Fig. 2-98-1
