ASTRO VG-871 - Settings Established Using Window Color Setting Command

Chapter 6 EXAMPLES OF USAGE
477
6.4.5 Settings established using window color setting command
Window color setting: Command [28H 62H]
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
WINCOL4
0×28
“(“
0×62
“b”
R
0×30
“0”
Delimiter
0×2C
“, “
G
0×30
“0”
Delimiter
0×2C
“, “
B
0×31
“2”
0×35
“5”
0×35
“5”
Delimiter
0×2C
“, “
Bit Mode
0×38
“8”
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
6.4.6 Settings established using square drawing command
Square drawing: Command [28H 23H]
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
CHASQRE4
0×28
“(“
0×23
“#”
Top left coordinate X
0×32
“2”
0×35
“5”
0×36
“6”
Delimiter
0×2C
“, “
Top left coordinate Y
0×31
“1”
0×39
“9”
0×32
“2”
Delimiter
0×2C
“, “
Bottom right coordinate X
0×31
“7”
0×30
“6”
0×32
“8”
Delimiter
0×2C
“, “
Bottom right coordinate Y
0×35
“5”
0×37
“7”
0×36
“6”
Delimiter
0×2C
“, “
Drawing mode
0×31
“1”
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
