ASTRO VG-871 - EXGDN4 [24 H 3 CH]: Execution of the Program Data in a Group

274
2.160 EXGDN4 [24H 3CH] : Execution of the program data in a
group
Function : this command executes the program data in a group.
Sequence : Type 2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
EXGPDN4
2 BYTE
24H 3CH
Setting NO
1-2 BYTE
"1"-"98"
ETX
1 BYTE
03H
Fig 2-160-1
Execution example
In case the group data has the following programs.
No
Timing No.
Pattern No.
1
1001
1001
2
1039
0
3
0
1045
4
1120
1001
5
1001
1010
Execute No.1  the timing and pattern data of No.1001 are executed.
Execute No.2  the timing data of No.1039 is output, and pattern data keeps the current status.
Execute No.3  the pattern data of No.1045 is output, the timing data keeps the current status.
Execute No.4  no timing data in No.1120 (in sample program of SP-8870) , it will show error.
Execute No.5  no pattern data in No.1010 (in sample program of SP-8870), it will show error.
PC
VG
STX～ETX
ACK or
STX+ESTS+Error Code+ETX
