*1 In VG-880, "1"=DEF2 cannot be used.
*2 If CF is inserted, it accesses to CF only. If CF is not inserted, it accesses to internal Flash only.
*3 In case of "0"=default IF, when changing, normal AV-Mute (disconnect sync) is executed. In case of
“1”=IF, sync does not disconnect in AV-MUTE.
*4 “0” = normal mode, “1”= this is the mode that coordinate information follows the cursor.
*5 The message is displayed while the designated time. After that, it goes back to the original.
*6 Set the digit number of Program No. that is input in Direct display.
*7 Refer to “SKEYL4 [20H 73H] : KEY LOCK data registering command” about key setting.
*8 The setting data is shown below.
Bit7
Bit0
0
1
0
0
CH 3
CH 2
CH 1
CH 0
Low=Off, High=On, Bit4 -7 are fixed.
*9 The setting data is shown below.
Bit7
Bit0
0
1
0
0
CH 3
CH 2
CH 1
CH 0
Low=Posi, High=Nega, Bit4 – 7 are fixed.
*10 The setting data is shown below.
Bit7
Bit0
0
1
0
0
CH 3
CH 2
CH 1
CH 0
Low = Trigger Delay Time 0
High = Trigger Delay Time 1
Bit4 – 7 are fixed.
*11 The setting data is shown below.
Bit7
Bit0
0
1
0
0
CH 3
CH 2
CH 1
CH 0
Low = Trigger Pulse Width 0
High = Trigger Pulse Width 1
Bit4 – 7 are fixed.
Note1) The above setting is made by VG-848 series Config setting.
Note 2) transfer byte number (command + parameter) should be within 1024 bytes.
If it is over 1024 bytes, it sends by several times by dividing the data.
Note3) the KeyLock data cannot be sent out to both VG-870 and VG-880 together.
*12 The setting data is shown below.
Bit7
Bit0
0
1
0
0
0
CH 2
CH 1
CH 0
Low = Off
High = On
Bit3 - 7 are fixed.
