Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
161
223
Key Lock ALL
1
“0” = OFF, “1” = LOCK
224
Key Lock TOP
1
“0” = OFF, “1” = LOCK
225
Key Lock MENU
1
“0” = OFF, “1” = LOCK
226
Key Lock NAME
1
“0” = OFF, “1” = LOCK
227
Key Lock HDCP
1
“0” = OFF, “1” = LOCK
228
Key Lock EDID
1
“0” = OFF, “1” = LOCK
229
Key Lock CEC
1
“0” = OFF, “1” = LOCK
230
Key Lock AUDIO
1
“0” = OFF, “1” = LOCK
231
Key Lock YPbPr
1
“0” = OFF, “1” = LOCK
232
Key Lock R
1
“0” = OFF, “1” = LOCK
233
Key Lock G
1
“0” = OFF, “1” = LOCK
234
Key Lock B
1
“0” = OFF, “1” = LOCK
235
Key Lock INV
1
“0” = OFF, “1” = LOCK
236
Key Lock UP
1
“0” = OFF, “1” = LOCK
237
Key Lock DOWN
1
“0” = OFF, “1” = LOCK
238
Key Lock RIGHT
1
“0” = OFF, “1” = LOCK
239
Key Lock LEFT
1
“0” = OFF, “1” = LOCK
240
KEY Lock RB
PATTERN
1
“0” = OFF, “1” = LOCK
Remote control keys
241
KEY Lock RB timing
1
“0” = OFF, “1” = LOCK
*Key lock items for VG-882, VG-883, VG-884 generator
300
Key Lock INC
1
“0” = OFF, “1” = LOCK
Front panel keys
301
Key Lock DEC
1
“0” = OFF, “1” = LOCK
302
Key Lock SET
1
“0” = OFF, “1” = LOCK
(for VG-882)
Key Lock TIM/PAT
1
“0” = OFF, “1” = LOCK
(for VG-883)
Key lock for remote control keys is same as VG-870 setting.
Remote control keys
Fig. 2-81-2
* This command sends only the above-listed key lock data of the system settings.
* The data is prepared on the basis of the SCFG4 [20H 54H] config data registration
command.
