ASTRO VG-871 - Page 192

178
3D Meta Present
1 BYTE
"0"=no meta data "1"= have meta data
,
1 BYTE
2CH (Delimiter)
3D Meta Type
1 BYTE
Fixed at "0"
,
1 BYTE
2CH (Delimiter)
3D Meta DataLength
1 to 2 BYTE
"0" to "21"
,
1 BYTE
2CH (Delimiter)
#1
3D Meta Data1
2 BYTE
"00" to "FF"
,
1 BYTE
2CH (Delimiter)
#19
3D Meta Data19
2 BYTE
"00" to "FF"
,
1 BYTE
2CH (Delimiter)
VendorSpec I/F Type
1 BYTE
"0"= others
"1"=HDMI 1.4b
“2”=HF-VSIF
,
1 BYTE
2CH (Delimiter)
3D Meta Data20
2 BYTE
"00" to "FF"
,
1 BYTE
2CH (Delimiter)
3D Meta Data21
2 BYTE
"00" to "FF"
,
1 BYTE
2CH (Delimiter)
Version
1 BYTE
"1"=1
,
1 BYTE
2CH (Delimiter)
3D Valid
1 BYTE
"0"=Disable, "1"=Enable
,
1 BYTE
2CH (Delimiter)
3D Additional Info
Present
1 BYTE
"0"=not Present、"1"=Present
,
1 BYTE
2CH (Delimiter)
3D Dual View
1 BYTE
"0"=Normal、"1"=Dual View
,
1 BYTE
2CH (Delimiter)
3D View Dependency
1 BYTE
"0"=No indication
"1"=Right View originates
"2"=Left View originates
"3"=Both Views
,
1 BYTE
2CH (Delimiter)
3D Preferred 2D View
1 BYTE
"0"=No indication
"1"=Right 3D view for 2D viewing
"2"=Left 3D view for 2D viewing
"3"=Don’t care.
,
1 BYTE
2CH (Delimiter)
3D Disparity Data
Present
1 BYTE
"0"=No Disparity Data, "1"=Disparity Data exists
,
1 BYTE
2CH (Delimiter)
3D Disparity Data Ver
1 BYTE
"0"=0, "1"=1, "2"=2
,
1 BYTE
2CH (Delimiter)
3D Disparity Data length
1 - 2 BYTE
"0" - "21"
,
1 BYTE
2CH (Delimiter)
#01
3D Disparity Data1
2 BYTE
"00" - "FF"
,
1 BYTE
2CH (Delimiter)
#21
3D Disparity Data31
2 BYTE
"00" - "FF"
ETX
1 BYTE
03H
Fig. 2-92-1
