ASTRO VG-871 - Page 233

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
219
,
1 BYTE
2CH (Delimiter)
Color G
(When L or R is set OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Color B
(When L or R is set OFF)
1-3 BYTE
"0"-"255"
,
1 BYTE
2CH (Delimiter)
Level L
(When L or R is set ON)
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
Level R
(When L or R is set ON)
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
OutputMode
1 BYTE
"0"=3D Structure "1"=Frame Sequential
,
1 BYTE
2CH (Delimiter)
Bit Mode
1-2 BYTE
"8"-"16"
,
1 BYTE
2CH (Delimiter)
LeftColor R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
LeftColor G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
LeftColor B
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
RightColor R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
RightColor G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
RightColor B
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
BackColorL R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
BackColorL G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
BackColorL B
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
HSize
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
VSize
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
HPosL
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
VPosL
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
UseLRColor
1 BYTE
"0"=Not Use
"1"=Use
,
1 BYTE
2CH (Delimiter)
HSize9
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
Vsize9
1-3 BYTE
"0"-"100%"
,
1 BYTE
2CH (Delimiter)
HPos9
1-3 BYTE
"0"-"100%"
,
1 BYTE
2CH (Delimiter)
VPos9
1-3 BYTE
"0"-"100%"
,
1 BYTE
2CH (Delimiter)
BackColorR R
1-5 BYTE
"0"-"65535"
,
,
,
BackColorR G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
BackColorR B
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
LRDisp
1 BYTE
"0"=OFF
"1"=display on top
"2"=display in center
,
1 BYTE
2CH (Delimiter)
LRBlackBack
1 BYTE
"0"=Not use, "1"=Use
,
1 BYTE
2CH (Delimiter)
SlantAngle
1-2 BYTE
"0"=0°
"1"=15°
