(5) “E” Change cursor color
Cursor color R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Cursor color G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Cursor color B
1 to 5 bytes
“0” to “65535”
Fig. 2-142-6
(6) “F” Change cursor coordinate
Cursor coordinate X
1 to 4 bytes
“0” to “4095”
,
1 byte
2CH (Delimiter)
Cursor coordinate Y
1 to 4 bytes
“0” to “4095”
,
1 byte
2CH (Delimiter)
SubPixel Mode
1 byte
"1" = R (in SubPixel increments)
"2" = G (in SubPixel increments)
"3" = B (in SubPixel increments)
* When SubPixel is turning on, it is effective.
* It operates by the unit of 1dot when omitted.
Fig. 2-142-7
(7) “G” Set subpixel to ON or OFF
SubPixel ON/OFF
1 byte
“0” = OFF, “1” = ON
Fig. 2-142-8
(8) “H” Set overlay to ON or OFF
Overlay ON/OFF
1 byte
“0” = OFF, “1” = ON
Fig. 2-142-9
(9) “I” Change of color of intersection point
Cross point color
1 byte
“0” = Normal (Not set to black)
“1” = Space (Set to black)
Fig. 2-142-10
(10) Exchange "J" Cursor1 and Cursor2
Cursor1, 2
1 byte
"0"=Cursor1, "1"=Cursor2
Fig2-142-11
(11) Exchange color of "K" Cursor 2
Cursor color R
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Cursor color G
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Cursor color B
1 to 5 bytes
"0" to "65535"
Fig2-142-12
(12) "L" Cursor 2Mode ON/OFF
Cursor 2Mode
1 byte
"0"=OFF、"1"=ON
Fig2-142-13
*1. This command is common command for cursor1 and cursor2
*2. This command is available for cursor1, in case “Exchange” is set for cursor1. In case
changing Cursor2, set the command for cursor2.
*3 Cursor2 is unable to set SubPixel.
