334
Palette No.
1-3 BYTE
"0"-"255" Palette No of graphic plane
,
1 BYTE
2CH (Delimiter)
R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
B
1-5 BYTE
"0"-"65535"
ETX
1 BYTE
03H
Fig 3-35-1
Note 1) The items below Bit Mode can be omitted. However, if you omit “color setting” part, you need to
delete both “plane code” and “color setting”. That is, if you set “color setting”, you need to input Bit Mode,
too.
Note 2) The Palette No. can be set maximum 16. Even if it is less than 16, it is okay to input.
Example) Omit character plane and background. Palette is set as “8”.
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
ALLSCOL4
2 BYTE
28H 70H
R
1 BYTE
"0"=OFF, "1"=ON
,
1 BYTE
2CH (Delimiter)
G
1 BYTE
"0"=OFF, "1"=ON
,
1 BYTE
2CH (Delimiter)
B
1 BYTE
"0"=OFF, "1"=ON
,
1 BYTE
2CH (Delimiter)
Bit Mode
1-2 BYTE
"0", "8"-"16"
In case it is set as “0”, RGB value is set as it is.
,
1 BYTE
2CH (Delimiter)
Plane Code
1 BYTE
"W" Window plane code
,
1 BYTE
2CH (Delimiter)
R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
B
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
#1
Palette No.
1-3 BYTE
"0"-"255" Palette No. of graphic plane
,
1 BYTE
2CH (Delimiter)
R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
B
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
#8
Palette No.
1-3 BYTE
"0"-"255" Palette No. of graphic plane
,
1 BYTE
2CH (Delimiter)
R
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
G
1-5 BYTE
"0"-"65535"
,
1 BYTE
2CH (Delimiter)
B
1-5 BYTE
"0"-"65535"
ETX
1 BYTE
03H
Fig 3-35-2
