(7) Window data
% = “0001” to “1000” (0.1 to 100.0%)
% = “0001” to “1000” (0.1 to 100.0%)
Fixed at “0” * This function cannot be used.
Fixed at “0” * This function cannot be used.
Fig. 4-7-8
(8) Optional pattern 1 data
Fig. 4-7-9
(9) Optional pattern 2 data
Fig. 4-7-10
(10) Color bar data
% = “0000” to “1000” (0.0 to 100.0%)
% = “0000” to “1000” (0.0 to 100.0%)
“0” = Horizontal, “1” = Vertical,
“2” = Repeated horizontally, “3” = Repeated
vertically
“0” = None “1” = R, “2” = G, “3” = RG, “4” = B, “5”
= RB, “6” = GB, “7” = RGB
Fig. 4-7-11
(11) Gray scale data
“0” = Horizontal, “1” = Vertical
To Next Page
