Chapter 4 INDIVIDUAL FORMATS FOR CONTROL COMMANDS
397
(C) Cursor shape
STX
1 byte
02H
TRDT
1 byte
10H
Cursor shape
1 byte
“0” = Full-screen cross cursor
“1” = Vertical line
“2” = 5×5 cross cursor
“3” = Full-screen cross cursor RGB
“4” = Vertical line RGB
“5” = 5×5 cross cursor RGB
ETX
1 byte
03H
Fig. 4-48-4
(D) Background color
STX
1 byte
02H
TRDT
1 byte
10H
R
3 bytes
“000” to “255”
G
3 bytes
“000” to “255”
B
3 bytes
“000” to “255”
ETX
1 byte
-
Fig. 4-48-5
(E) Cursor color
STX
1 byte
02H
TRDT
1 byte
10H
R
3 bytes
“000” to “255”
G
3 bytes
“000” to “255”
B
3 bytes
“000” to “255”
ETX
1 byte
03H
Fig. 4-48-6
(F) Cursor coordinates
STX
1 byte
02H
TRDT
1 byte
10H
X coordinate
4 bytes
From “0000” to “H display size -1 (4 digits)”
Y coordinate
4 bytes
From “0000” to “V display size -1 (4 digits)”
ETX
1 byte
03H
Fig. 4-48-7
