Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
33
Ch2 SW2
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
,
1 byte
2CH (Delimiter)
Ch2 SW3
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
,
1 byte
2CH (Delimiter)
Ch3 Output Enable
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch3 Clock
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch3 Sync
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch3 Power
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch3 RGB Polarity
1 byte
“0” = Nega, “1” = Posi
,
1 byte
2CH (Delimiter)
Ch3 SW1
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
,
1 byte
2CH (Delimiter)
Ch3 SW2
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
,
1 byte
2CH (Delimiter)
Ch3 SW3
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
,
1 byte
2CH (Delimiter)
Ch4 Output Enable
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch4 Clock
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch4 Sync
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch4 Power
1 byte
“0” = Hi-Z, “1” = ON
,
1 byte
2CH (Delimiter)
Ch4 RGB Polarity
1 byte
“0” = Nega, “1” = Posi
,
1 byte
2CH (Delimiter)
Ch4 SW1
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
,
1 byte
2CH (Delimiter)
Ch4 SW2
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
,
1 byte
2CH (Delimiter)
Ch4 SW3
1 byte
“0” = CS, “1” = VD, “2” = HD, “3” = Low, “4” = High
ETX
1 byte
03H
Fig. 2-7-1
