482
Window drawing: Command [28H 61H]
(1) Window at top left
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
WINDOW4
0×28
“(“
0×61
“a”
Top left coordinate X
0×32
“2”
0×35
“5”
0×36
“6”
Delimiter
0×2C
“, “
Top left coordinate Y
0×31
“1”
0×39
“9”
0×32
“2”
Delimiter
0×2C
“, “
Bottom right coordinate X
0×34
“4”
0×30
“0”
0×36
“6”
Delimiter
0×2C
“, “
Bottom right coordinate Y
0×33
“3”
0×34
“4”
0×32
“2”
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
If only setting 1. is set, window will be drawn as below.
Horizontal line memory
Vertical line memory
