62
,
1 byte
2CH (Delimiter)
Group pattern interval 2
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern interval 3
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern interval 4
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern step H1
1 to 4 bytes
“1” to “4095”
,
1 byte
2CH (Delimiter)
Group pattern step H2
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern step H3
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern step H4
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern step V1
1 to 4 bytes
“1” to “4095”
,
1 byte
2CH (Delimiter)
Group pattern step V2
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern step V3
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Group pattern step V4
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Number of group pattern
repetitions H
1 or 2 bytes
“1” to “15”
,
1 byte
2CH (Delimiter)
Number of group pattern
repetitions V
1 or 2 bytes
“1” to “15”
,
1 byte
2CH (Delimiter)
Window scroll mode
1 or 2 bytes
“0” = Left, “1” = Right, “2” = Up, “3” = Down,
“4” = Top left, “5” = Bottom left, “6” = Top right,
“7” = Bottom right, “8” = LR, “9” = UD, “10” = Random
,
1 byte
2CH (Delimiter)
Window interval 1
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
Window interval 2
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window interval 3
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window interval 4
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step H1
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step H2
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step H3
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step H4
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step V1
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step V2
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step V3
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window scroll step V4
1 to 3 bytes
“0” to “255”
,
1 byte
2CH (Delimiter)
Window level change
direction
1 byte
“0” = Low → High, “1” = High → Low
,
1 byte
2CH (Delimiter)
Window level change
interval
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
Window level change
step
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
Character pull-down
mode
1 byte
“0” = User, “1” = 60i → 60i, “2” = 24p → 60i,
“3” = 25p → 50i, “4” = 30p → 60i
