1 byte
2CH (Delimiter)
Audio Internal Level 5
1 to 7 bytes
“0” to “8388607”
,
1 byte
2CH (Delimiter)
Audio Internal Level 6
1 to 7 bytes
“0” to “8388607”
,
1 byte
2CH (Delimiter)
Audio Internal Level 7
1 to 7 bytes
“0” to “8388607”
,
1 byte
2CH (Delimiter)
Audio Internal Level 8
1 to 7 bytes
“0” to “8388607”
,
1 byte
2CH (Delimiter)
Audio Internal Freq 1
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882,
100 Hz to “1/2 of frequency set by Audio Sample”
For 1,3, 5, 7 ch.
,
1 byte
2CH (Delimiter)
Audio Internal Freq 2
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882,
100 Hz to “1/2 of frequency set by Audio Sample”
For 2, 4, 6, 8 ch.
,
1 byte
2CH (Delimiter)
Audio Internal Freq 3
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882, no setting.
,
1 byte
2CH (Delimiter)
Audio Internal Freq 4
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882, no setting.
,
1 byte
2CH (Delimiter)
Audio Internal Freq 5
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882, no setting.
,
1 byte
2CH (Delimiter)
Audio Internal Freq 6
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882, no setting.
,
1 byte
2CH (Delimiter)
Audio Internal Freq 7
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882, no setting.
,
1 byte
2CH (Delimiter)
Audio Internal Freq 8
2 to 5 bytes
20 Hz to “1/2 of frequency set by Audio Sample”
* In case of VG-882, no setting.
,
1 byte
2CH (Delimiter)
Audio Data No 1
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio Data No 2
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio Data No 3
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio Data No 4
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio Data No 5
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio Data No 6
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio Data No 7
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio Data No 8
1 or 2 bytes
“1” to “99” audio data No.
,
1 byte
2CH (Delimiter)
Audio LPCM
1 byte × 8
“0” = OFF, “1” = ON (1CH to 8CH)
ETX
1 byte
03H
Fig. 2-21-1
