ASTRO VG-871 - Page 95

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
81
AVI Picture Aspect
1 byte
“0” = No Data, “1” = 4:3, “2” = 16:9
,
1 byte
2CH (Delimiter)
AVI Colorimetry
1 byte
“0” = No Data
“1” = SMPTE
“2” = ITU709
"3" = Extend
,
1 byte
2CH (Delimiter)
AVI Video Code
1 or 2 bytes
“0” to “107”
,
1 byte
2CH (Delimiter)
AVI Repetition
1 or 2 bytes
“1” to “10”
,
1 byte
2CH (Delimiter)
AVI TopBar
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
AVI BottomBar
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
AVI LBar
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
AVI RBar
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
AVI Scaling
1 byte
“0” = Unknown, “1” = Horiz, “2” = Vert,
“3” = Horiz&Vert
,
1 byte
2CH (Delimiter)
AVI QuantRange
1 byte
“0” = Default, “1” = Limited, “2” = Full
,
1 byte
2CH (Delimiter)
AVI ExtColor
1 byte
"0"=xvYCC601
"1"=xvYCC709
"2"=sYCC601
"3"=AdobeYCC601
"4"=AdobeRGB
“5”=ITU-R BT.2020 Y’cC’bcC’rc
“6”=ITU-R BT.2020 R’ G’ B’ or Y’ C’bCr
,
1 byte
2CH (Delimiter)
AVI ITContent
1 byte
“0” = No Data, “1” = IT Content
,
1 byte
2CH (Delimiter)
SPD Type
1 byte
“3” = 3
,
1 byte
2CH (Delimiter)
SPD Ver
1 byte
“1” = 1, “2” = 2
,
1 byte
2CH (Delimiter)
SPD Vendor Name
8 bytes
* 8 ASCII characters (When the string contains fewer
than 8 characters, enter a space or spaces after
the characters to bring the number of characters up
to 8)
,
1 byte
2CH (Delimiter)
SPD Product
16 bytes
* 16 ASCII characters (When the string contains
fewer than 16 characters, enter a space or spaces
after the characters to bring the number of
characters up to 16)
,
1 byte
2CH (Delimiter)
SPD Source Device
1 byte
"0"=unknown
"1"=DigiSTB
"2"=DVD
"3"=DVHS
"4"=HDD
"5"=DVC
"6"=DSC
"7"=CD
"8"=Game
"9"=PC
"10"=Blu-Ray(BD)
"11"=Super Audio CD
"12"=HD DVD
"13"=PMP
,
1 byte
2CH (Delimiter)
Audio Type
1 byte
“4” = 4
,
1 byte
2CH (Delimiter)
Audio Ver
1 byte
“1” = 1
,
1 byte
2CH (Delimiter)
Audio Channel Count
1 byte
“0” = Refer, “1” = 2ch, “2” = 3ch, “3” = 4ch, “4” = 5ch,
“5” = 6ch, “6” = 7ch, “7” = 8ch
