Talk Indicator:
This LED light up if PCP is allowed to paging, on the other word, the paging request has been
acknowledged.
Sometime after paging request is granted, zones under paging still can be occupied by other
sources. In such a case, the talk LED still light up, but you can check busy LED to know the
situation.
Hold Indicator (1~8):
These LEDs Indicate which keys are selected.
All Call/Release Button:
This button is used for selecting or deselecting all keys.
All Call/Release Indicator:
This indicator lights up if all keys are selected.
Event Select Key (1~8):
These buttons are used to select keys, each key may link to an event for triggering actions like
paging or adjust the value of parameters.
Busy Indicator (9~16):
Please refer to Busy Indicator (1~8).
Hold Indicator(9~16):
Please refer to Hold Indicator(1~8).
Event Select Key(9~16):
Please refer to Event Select Key(9~16).
3.2.1.8.2 Configuration
The example here is the IDA8 system, the configuration is the same for ESC, LAPG2T and other
Ateis Audio Processor.
Create PCP Object
1. Open or create a Ateis studio configuration file.
2. Drag IDA8C object to the design window to create an audio processor object.
3. Drag PPM-AS to the design window to create PCP object.
"PPM AS, PCP, PSC and CDPM share the same object.
4. Wiring to connect green pins between PCP object and audio processor.
